Air Purification Equipment Customization Panel Class 100 Clean Room Industrial Hot Selling Dust Protected Clean Room

1.0 Sets
MOQ
Air Purification Equipment Customization Panel Class 100 Clean Room Industrial Hot Selling Dust Protected Clean Room
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Condition: New
Applicable Industries: Manufacturing Plant, Energy & Mining, Hospital, Food and Health Care Plant, Electronics, Solar Energy Industry, Bio-industry
Weight (KG): 200
Showroom Location: None
Video outgoing-inspection: Provided
Machinery Test Report: Not Available
Marketing Type: Field Engineering
Warranty of core components: 1 Year
Core Components: Sandwich Panel, Pass Box, Air Filtration System
Warranty: 1 Year
After-sales Service Provided: Online support
Product name: Dust-Free Cleanroom
sterile laboratories: 10,000 Level (ISO 7)
Application: Industrial
Type: Clean Room Booth
Size: Customsize
Name: Cleanroom Project
Material: Stainless Steel
Function: Purification Filter
Usage: Air Purification System
Basis informatie
Betalen & Verzenden Algemene voorwaarden
Packaging Details: Customerized
Supply Ability: 5 Set/Sets per Month
Productomschrijving
Company Profile
Main Products
Products Description
Parameter
Softwall Clean Booth
Hardwall Clean Booth
Cleanliness
From Class 100 to Class 1000,000
External Dimension
As per requirement

FFU
Dimension
2'X4'
Cabinet Material
Stainless Steel
Power source
110V/60hz/av/dc, 220V/60HZ/AV/DC
HEPA Filter
H14 Hepa filter
Frame Material
Stainless Steel
Wall Material
Fireproof Rock Wool Sandwich Panel
Floor Material
Epoxy resin self flow floor, epoxy resin coating floor, PVC makeup floor, etc.
Anti-static acrylic 106~109Ω
Lighting
Lamps
Available in LED and T5
Air condition
As per requirement
Available in constant temperature air conditioner/constant temperature and humidity conditioner

Additional Information

(1) Changing rooms and main laboratory have air velocity of over 0.3 m/s. Air shower air velocity should be at least 15 m/s. Air pressure disparity between main clean areas and outside areas should be at least 5 Pa. Interior noise level should not exceed 60 db.  (2)    Level 2 sterile laboratories are 10,000 Level (ISO 7) in all areas, and 100 Level (ISO 5) in workstations and other critical areas. (3)    The air filtration system for level 2 laboratories includes initial, intermediate, and high-efficiency HEPA filters. These laboratories should employ laminar air flow. Air showers and changing room equipment (sinks, etc.) should all be automatic. (4)   Level 3 sterile laboratories are similar to level 2 sterile laboratories in many ways, but they have additional purification equipment to ensure an even more sterile environment. Level 3 laboratories have self-leveling epoxy resin floors, and are equipped with electronic door locks, interlocking pass boxes, and equipment for disinfecting pipes in the laboratory. (5) Most sterile laboratories are negative pressure environments. The lab itself should have a pressure disparity of 30-40 Pa, while the buffer area should have a disparity of 15-20 Pa.
Can be customized according to requirements
Click to contact us for more details
